| Vehicle Category | L5M - Passenger Vehicle |
|---|---|
| Model | Tricity+ |
| Vehicle Body | Full Metal Body with soft rooftop |
| Seating Capacity | 6+1D |
| Dimensions | 120 L x 1375 W x 1880 H mm |
| Wheel Base | 2130 mm |
| Ground Clearance | 130 mm |
| Rear Track | 1185 |
| Vehicle Kerb Weight | 589 kg |
| Tray Size (Internal Dimensions) | 1800 L x 1450 W x 280 H mm |
| Tire Size | 4.50 x 10 - 8 PR |
| Top Speed | 55 km/hr |
|---|---|
| Certified Range | 145 km* |
| Gradability | 22.48% |
| Charging Time with Home Charger | 6 hr 30 min |
| Fast Charging @100A | 2 Hours* |
| Battery Type | LiFePo4 |
|---|---|
| Battery Capacity | 10.24 kWh |
| Motor Type | Magnet-less switch reluctance motor |
|---|---|
| Pick Power | 7.3 kW |
| Pick Torque | 74.60 Nm |
| Transmission Type | Direct drive |
| Front Suspension | Helical compression spring with damper |
|---|---|
| Rear Suspension | Leaf spring with damper |
| Brake - Front/Rear | Hydraulic double acting |
|---|---|
| Parking Brake | Mechanical lever type |
- 0.75 Rs/km low running cost.
- Low maintenance.
- Gradient gear for easy climbing with a heavy load.
- Digital instrument cluster.
- Spacious and comfortable seats for a driver and passengers.
- Strong tubular chassis for worry-free heavy load-carrying.
- Front suspension with double helical compression spring.
- Clutch & Gearless drive.
- Noiseless and Vibration-free drive.
- Dust and Water Proof Power Train.
- Smart Lithium-ion Battery.
- Anti-slip-down protection and hill assistance function.
- Regenerative Braking.
- Driving Modes: Drive, Neutral, Reverse.
- Speed Modes: Eco, Speed, Power.
- Big Metal Lockable Glove box.
- Telematics Units & GPS*.
- Offboard Home Charger.
- USB Mobile Charger, Bottle Holder, Hazard Indicator, Cabin Light.
